Technolloy Inc. has emerged to accomplish a massive market position as the suppliers of ferrous and non-ferrous metals in the advanced market. We creation and produce Incoloy 800/800HT/825 Pipes and Tubes according to the necessities and solicitations of the clients.
Incoloy in any case called first class execution compounds are the super composites which give high security from utilization and oxidation. At raised temperatures it gives mechanical strength. Incoloy 800/800HT/825 Pipes &Tubes can be introduced in welded, reliable or welded and cold construction dependent upon the mix the client requires. Incoloy super composites are extensively used by current radiators, nuclear planning strain vessels, and warmers in power plants. These are in like manner used in substance taking care of, crush and paper, and force exchangers.
Incoloy 800/800HT/825 Pipes and Tubes are used in the nuclear power plant and paper squash industry. These chambers are commonly used in changing radiators of steam methane and moreover in ousted tubing. They are created both reliable as well as welded structures. These lines are extremely impenetrable to disintegration, whether or not it is in an acidic environment. It is used in an extensive range by various organizations generally through the world for different applications, especially for those which oversee temperatures around 600 Degree C.
It will in general be used in an environment without costing any damage. These are fundamentally expected in pound and paper adventures, gas, oil, and petrochemicals. Nickel, chromium, and manganese are used to make Incoloy 800/800HT/825 Pipes and Tubes which helps with supporting the thing and which moreover gives solidness to the thing.
Incoloy 800/800HT/825 Pipes and Tubes comes in different shapes and sizes. These are of the mind-boggling interest in individuals who produce the taking off grades of material. These chambers are very flexible to breaking down as well as in the acidic circumstances. Its end is similarly of three sort's plain end, calculated end and ventured.
To check the quality and strength of the lines a couple of tests is done like pitting test, hardness test, emitting test, evening out test. To keep the lines and chambers from a couple of normal damages they are squeezed and conveyed into wooden beds, containers, etc.
800/800HT/825 Incoloy Pipes and Tubes Equivalent Grades
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
---|---|---|---|---|---|---|---|---|
Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32T |
Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | - | X8NiCrAlTi32-21 | XH32T |
Incoloy 825 | 2.4858 | N08825 | NCF 825 | NA 16 | ЭП703 | NFE30C20DUM | NiCr21Mo | XH38BT |
Specification of Incoloy Seamless Welded Pipes And Tubes
Incoloy Pipe Specification : ASTM B407, B514 / ASME SB407, SB514
Incoloy Tube Specification : ASME / ASTM SB/B 407 / SB/B 515
Standard : ASTM, ASME and API
Tube Size : 15"NB – 150"NB
Thickness Range : 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
Chemical Composition of Incoloy Alloy Seamless / Welded Pipes and Tubes
Incoloy | 800 | 800H | 825 |
---|---|---|---|
Ni | 30-35 | 30-35 | 38.0 – 46.0 |
Fe | 39.5 min | 39.5 min | 22.0 min |
Cr | 19-23 | 19-23 | 19.5 - 23.5 |
Cu | 0.75 max | 0.75 max | 1.5 - 3.0 |
Ti | 0.15-0.60 | 0.15-0.60 | 0.6 - 1.2 |
Al | 0.15-0.60 | 0.15-0.60 | 0.2 max |
C | 0.1 max | 0.05-0.1 | 0.05 max |
Mn | 1.5 max | 1.5 max | 1.0 max |
S | 0.015 max | 0.015 max | 0.015 max |
Si | 1.0 max | 1.0 max | 0.5 max |
Mb | - | - | 2.5 - 3.5 |
Mechanical Properties of Incoloy Alloy 800/800HT/825 Pipes and Tubes
Inconel 800/800HT | |
---|---|
Tensile Strength | Psi – 75,000 , MPa – 520 |
Yield Strength (0.2%Offset) | Psi – 30,000 , MPa –205 |
Elongation | 30 % |
Inconel 825 | |
Tensile Strength | Psi – 80,000 , MPa – 550 |
Yield Strength (0.2%Offset) | Psi – 32,000 , MPa –220 |
Elongation | 30 % |
Physical Properties of Incoloy 800/800HT Pipes and Tubes
Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
---|---|---|---|---|---|---|
at 68°F: 0.285 | 9.4 at 212°F | 28.3 at 68°F | 28 | 9.4 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500 to 2590 |
12.4 at 932 °F | 39.4 at 752°F | 10.2 at 32 – 1000°F | ||||
49.6 at 1652 °F | 10.4 at 32 – 1500°F |
